SDSS-V: Pioneering Panoptic Spectroscopy

Multi-Object Spectroscopy: optical & near-IR, all-sky, multi-epoch
Integral Field Spectroscopy: optical, 3000 deg2, ultra wide-field

Image Credit: Juna A. Kollmeier and Hans-Walter Rix

Although SDSS-IV will keep collecting and publishing data until 2020, we are excitedly planning for SDSS-V, a panoptic spectroscopic survey that will continue the SDSS tradition of innovative data and collaboration infrastructure. SDSS-V will be the first facility providing multi-epoch, all-sky, optical & IR spectroscopy, as well as offering contiguous integral-field spectroscopic coverage of the Milky Way and Local Volume galaxies.

Our white paper SDSS-V: Pioneering Panoptic Spectroscopy contains a fuller description of the survey’s ambitious goals and scope.


SDSS-V will be carried out in both hemispheres, at Apache Point Observatory (APO) in the USA and Las Campanas Observatory (LCO) in Chile. Multi-object fiber spectroscopy will be obtained with two 2.5m telescopes, each feeding a near-infrared APOGEE spectrograph and an optical BOSS spectrograph, for the Milky Way Mapper and Black Hole Mapper programs. The Local Volume Mapper will make use of smaller telescopes at APO and LCO to perform its optical integral-field spectroscopy. <i>Image credit: M. Seibert (OCIS) & SDSS-V team.</i>
SDSS-V will be carried out in both hemispheres, at Apache Point Observatory (APO) in the USA and Las Campanas Observatory (LCO) in Chile. Multi-object fiber spectroscopy will be obtained with two 2.5m telescopes, each feeding a near-infrared APOGEE spectrograph and an optical BOSS spectrograph, for the Milky Way Mapper and Black Hole Mapper programs. The Local Volume Mapper will make use of smaller telescopes at APO and LCO to perform its optical integral-field spectroscopy. Image credit: M. Seibert (OCIS) & SDSS-V team.

Overview

SDSS-V is an all-sky, multi-epoch spectroscopic survey that will yield optical and IR spectra of over 6 million objects during its five year lifetime (2020-2025). Using SDSS’s existing and anticipated new facilities at Apache Point Observatory and Las Campanas Observatory, SDSS-V will survey the entire sky — mapping the Milky Way using rapid, repeated observations, mapping Local Volume galaxies using wide-angle integral field spectroscopy, and mapping black holes using time domain spectroscopy of quasars and bright X-ray sources. Instead of SDSS’s classic plugplate system, SDSS-V will use a new, custom-built robotic positioning system to allow for rapid configuration of fibers. These fibers will lead to the existing APOGEE and BOSS spectrographs, enabling simultaneous IR and optical observations. In addition, new wide-field integral-field units are being deployed to observe the stars and interstellar medium in the Milky Way, Magellanic Clouds, and local galaxies such as M31 at unprecedented spatial resolution.

More information about SDSS-V and its place in the astronomical landscape during the 2020s can be found in our white paper SDSS-V: Pioneering Panoptic Spectroscopy.

Mappers

SDSS-V comprises three key programs, called Mappers:

The Milky Way Mapper (MWM) will target 4-5 million stars across the Milky Way, collecting infrared spectra with an APOGEE spectrograph and/or optical spectra with a BOSS spectrograph. The MWM seeks to understand the evolution of the Milky Way, the physics of its stars and interstellar medium, and the architecture of multiple-star and planetary systems.

The Black Hole Mapper (BHM) will target over 400,000 sources, primarily black holes, with a BOSS optical spectrograph. Many of these will be observed numerous times, with the goal of measuring black hole masses, probing black hole growth across cosmic time, and characterizing the X-ray sky.

The Local Volume Mapper (LVM) will observe the interstellar medium and stellar populations in the Milky Way and several local galaxies, collecting more than 25 million contiguous spectra over 3,000 square degrees on the sky. The LVM will use new integral-field spectrographs to explore the physics of star formation and the interactions between stars and the interstellar medium.

Click on the Mapper buttons below for more details.

Milky Way Mapper

MWM

A time-domain spectroscopic survey of Milky Way stars of all types.
Image credit: ESA/Gaia/DPAC
Explore the Milky Way Mapper
Program Head: Jennifer Johnson (The Ohio State University)

Black Hole Mapper

BHM

A time-domain spectroscopic survey of quasars and X-ray sources.
Image credit: ESO/M. Kornmesser
Explore the Black Hole Mapper
Program Head: Scott Anderson (University of Washington)

Local Volume Mapper

LVM

An integral-field spectroscopic survey of the Milky Way and its galactic neighbors.
Image credit: NASA, ESA/A. Nota
Explore the Local Volume Mapper
Program Head: Niv Drory (University of Texas at Austin)

Join us!

SDSS-V, like previous SDSS surveys, will remain committed to making its data publicly available in a format that is helpful to a broad range of users, from beginner students to both amateur and professional astronomers. However, without federal or other large-scale funding, this commitment is not possible without membership contributions from institutional partners. SDSS-V is currently under development and actively seeking funding from partners. Our institutional partners benefit from early access to data, participation in the survey planning process, and involvement of their faculty, postdocs, and students in the science collaborative network.

Policies for joining the program can be found in the Joining Document, and special policies for those joining both SDSS-V and SDSS-IV can be found in the Joint SDSS-V and SDSS-IV Membership Document. The general policies for SDSS-V are defined in its current Principles of Operation; the member institutions will review these policies prior to the start of SDSS-V operations.

Leadership and contact information

SDSS-V is led by Director Juna A. Kollmeier (Carnegie Observatories) and Project Scientist Hans-Walter Rix (Max-Planck-Institut für Astronomie), with support from their Management Committee and the SDSS-V Advisory Council.

For more information about SDSS-V, please contact Director Juna Kollmeier or SDSS-V Spokesperson Gail Zasowski (University of Utah).
